Construction

Conductors: Flexible Stranded Bare Copper Conductors

Insulation: PVC

Jacket: Yellow PVC (black on request)

Color: 1. Black 2. Red 3. Blue 4. Orange 5. Yellow 6. Brown 7. Red/Black 8. Blue/Black 9. Orange/Black 10. Yellow/Black 11. Brown/Black 12. Black/Red

Features
- Flat flexible construction

-Rated for indoor and outdoor use

-Durable Oil Resistant Outer Jacket

- (UL) VW-1 / CSA FT1 – Rated -40° C to 90° C

Approvals

-(UL) Festoon 600V 105° C

-(UL) AWM 600V 105°

-CSA Festoon 600V 105° C

Technical details

Temperature range: -40° C to 105° C (static), -10° C to 70° C (dynamic)

AC Voltage Rating: 600 V/2000V Peak

Bend Radius: 5x Cable Thickness

Construction

Conductors: Flexible Stranded bare Copper Conductors

Insulation: PVC/Nylon Insulation

Jacket: Yellow PVC (black on request)

Color: Per ICEA Method1, Table E-2 with one Green/Yellow ground conductor

Features

-Flexible construction

-Durable Oil Resistant Outer Jacket

Approvals

-UL Pendant 600V 90° C

-Type MTW

-CSA AWM 600V 90° C

Technical details

Temperature range: 90°

AC Voltage Rating: 600 V

Construction

Conductors: Flexible Stranded Bare copper, ASTM B-174 and UL 62

Insulation: Ethylene-propylene rubber (EPR), 90°C compound class 3, table 8, UL 62

Assembly: Insulated conductors cabled together with integral filler or rubber fillers

Separator: Talc for 18-10 AWG (portable & control cable), Talc for 8-2 AWG (power cable)

Jacket: Black CPE 90°C compound class 1.4, table 22, UL 62

Features

-Excellent flexibility, resistance to oil, solvents, ozone, weather, sunlight and water

-Flame test meets VW-1, FT2 and MSHA

-Temperature range -40°C to + 90°C

-Suitable for shallow water immersion

-NEC Article 700 permitted for specific applications

-NFPA 70 permitted use in Hazardous Locations Classes I, II, III Divisions 1 & 2 as outlined in Articles 501, 502, 503 section 140.

-Bend radius: 5 x OD

Approvals
-UL
-CSA
-MSHA

Specification and Standards

-UL62/CSA-C 22.2 No. 4

Construction

Body Material: Aluminum (other materials available on request)

Bushing Material: Neoprene

Nut: Aluminum

Features and Specifications

-Indoor and outdoor locations

-Termination with both mechanical & environmental integrity which minimizes the incidence of disconnector power

- IP 54 and Nema 3/3R, IP 65 and Nema 4, IP 67 and Nema 6, IP 52 and Nema 12 (Aluminum)

-Temperature -40° / 150° C (Aluminum)

Approvals

-UL

-CSA

-NEC

-ROHS & WEE

Application

Specifically designed for flat cable, festoon application, heavy-duty.

-Drum Reeling Cable
- High and Low temp
- Oil water chemical resistant
-TPC Medium Duty

-I-Beam D, E, and F Class Trolleys
- Indoor and Outdoor
-High Temp
-Control, Power, Hydraulic and Air

Power Track
- Medium and Heavy Duty
-Indoor and Outdoor
-High Temp
-Galvanized, FRP, and Stainless

Medium Duty C-Track
-Galvanized and C-Track
-Indoor and Outdoor
-Control, Power, and AIr

Equipt Push Button Pendants
-2 to 12 buttons in standard configuration
-Specialty Inserts and Accessories
- 1,2, and 3 speed inserts
-Pilot Lights
- Selector Switches
- Toggle Switches
- E- Stop

Cable
-Master Cable Reels

Hose Reels

Series S Reels

Series MMD and SM Mill Duty Reels

Series SHO and TMR Reels

35 Series Medium Duty Festoon Track

• Hangars

• Joints

• Support Arms

• End stops and clamps

• Control and Tow Trolleys

• Round and Flat Trolleys




• Cable Gland/ Connector/ Lug/ Termination

• Kellems Grip

• Cables Sleeve

• Cable Tie

• Insulation Tape

• Heat Shrink/ Marking Solution

• Enclosures

• Lubricant/ Grease
